LB型冷冻机用齿轮泵
相关参数
|
型号 |
流量m3/h |
工作压力MPa |
进出口径mm |
允许吸上高度m |
传动形式 |
配用功率 |
泵效率% |
转数r/min |
介质温度≤℃ |
重量kg |
应用范围 |
||
|
减速机型号 |
三角带型号 |
电机型号 |
功率kw |
||||||||||
|
LC10/0.6 |
10 |
0.6 |
40 |
6 |
ZD14 |
A1778 |
YB100L2-4 |
3.0 |
62 |
400 |
140 |
167 |
柴油 机油 甘油 石油 牙膏 食用油 |
|
LC18/0.6 |
18 |
0.6 |
50 |
6 |
ZD14 |
A1778 |
YB132S-4 |
5.5 |
62 |
400 |
140 |
219 |
|
|
LC38/0.6 |
38 |
0.6 |
65 |
6 |
ZD14 |
B2350 |
YB132M-4 |
7.5 |
65 |
400 |
140 |
269 |
|
|
LC50/0.6 |
50 |
0.6 |
80 |
6 |
ZL200 |
|
YB180M-4 |
11 |
70 |
445 |
140 |
1160 |
|
|
LC80/0.6 |
80 |
0.6 |
200 |
6 |
ZL23.1 |
|
YB225M-6 |
30 |
70 |
209 |
140 |
|
|
|
LC100/0.6 |
100 |
0.6 |
200 |
6 |
ZL23.1 |
|
YB250M-6 |
37 |
73 |
254 |
140 |
|
|
|
LCT10/0.6 |
10 |
0.6 |
40 |
6 |
ZD14 |
A1778 |
YB100L2-4 |
3.0 |
62 |
400 |
140 |
167 |
汽油 溶剂油 煤油等 |
|
LCT18/0. |
18 |
0.6 |
50 |
6 |
ZD14 |
A1778 |
YB132S-4 |
5.5 |
62 |
400 |
140 |
219 |
|
|
LCT38/0.6 |
38 |
0.6 |
65 |
6 |
ZD14 |
B2350 |
YB132M-4 |
7.5 |
65 |
400 |
140 |
269 |
|
|
LCT50/0.6 |
50 |
0.6 |
80 |
6 |
ZL200 |
|
YB160M-4 |
11 |
70 |
445 |
140 |
1160 |
|
|
LCT80/0.6 |
80 |
0.6 |
200 |
6 |
ZL23.1 |
|
YB180M-4 |
30 |
70 |
209 |
140 |
|
|
|
LCT100/0.6 |
100 |
0.6 |
200 |
6 |
ZL23.1 |
|
YB200L-4 |
37 |
73 |
254 |
140 |
|
|
|
LCW10/0.6 |
10 |
1.0 |
40 |
6 |
ZD14 |
A1778 |
YB100L2-4 |
3.0 |
60 |
400 |
140 |
167 |
沥青 冷凝油 稠油等 |
| 型号 | 吸入及排出端口径（mm） | 规定流量 | 压差（MPa） | 排出压力 p Mpa | 电动机 | |||
| m3/h | L/min | 功率KW | 转速r/min | 型号 | ||||
| LB1.8 | 20 | 1.8 | 30 | 0.5 | 2.5 | 0.55 | 1390 | Y801-4 |
| LB3.6 | 25 | 3.6 | 60 | 0.5 | 2.5 | 1.1 | 910 | Y90L-6 |
| LB10 | 40 | 10 | 166.7 | 0.5 | 2.5 | 3 | 1420 | Y100L2-4 |
| LB12 | 40 | 12 | 200 | 0.5 | 2.5 | 3 | 1420 | Y100L2-4 |
| LB20 | 80 | 20 | 333.3 | 0.5 | 2.5 | 5.5 | 960 | Y132M2-6 |
| LB25 | 80 | 25 | 416.7 | 0.5 | 2.5 | 7.5 | 970 | Y160M-6 |
| LB40 | 100 | 40 | 666.7 | 0.5 | 2.5 | 11 | 970 | Y160L-6 |
